Generator Engine Controller Module LED Indicator DSE501K Genset Start Controller DC9?33V AC15?305V

€72.69
+ €12.49 Shipping

Generator Engine Controller Module LED Indicator DSE501K Genset Start Controller DC9?33V AC15?305V

Sold by:
  • product image
  • product image
  • product image
  • product image
  • product image
Generator Engine Controller Module LED Indicator DSE501K Genset Start Controller DC9?33V AC15?305V

€72.69

In stock
+ €12.49 Shipping

14-Day Returns Policy

Payment methods:

  • Brand: Unbranded

Description

Generator Engine Controller Module LED Indicator DSE501K Genset Start Controller DC9?33V AC15?305V

Item Type: Generator Engine Controller Module <br>Material: ABS <br>DC Supply: Continuous 9-33 V <br>Alternator Input Range: 15-305 V AC RMS <br>Alternator Input Frequency: 50-60Hz at rated engine speed <br>Magnetic Input Range: 0.5V - +/- 80V <br>Magnetic Input Frequency: 2300Hz-6000Hz F. <br>Starter Relay Products: 16 Amp DC at supply voltage <br>Continuous Staging Products: 16 Amp DC at supply voltage H <br>Alarm Products: 1Amp DC at supply voltage <br>Operating Temperature Range: 30-70℃<br>1、Genset Start Controller: The user can use the key switch and panel start button to control the generator set to start or stop, it is a manual engine control module. <br>2、Panel Alarm: The controller has panel alarms, including low battery voltage, overspeed, high water temperature, low oil pressure, stop and running status indicators, which can monitor the generator working status. <br>3、LED Indicator: After the controller's alarm output is output, the associated LED will remain lit until the switch is turned to the O position to reset the module. <br>4、Restart: The engine starts and the alarm input is suppressed for a short period of time afterwards, after the delay the input will restart and the module provides normal operational protection. <br>5、WL Terminal: The charge fault alarm also provides the WL terminal for monitoring the charge generator, and the module also supplies excitation current to the alternator through this connection.1 x Generator Engine Controller Module<p>2 x Key</p><p>1 x Instruction</p>
  • Fruugo ID: 385807351-829233041
  • EAN: 3524841293126
